Diatermo MB 200W Touch

download
catalogue page
operator
manual

SKU: 21893 Category: Other Tag: DIATERMO MB 200W TOUCH

Description

DIATERMO MB 200W TOUCH

High Frequency electrosurgical equipment suitable for precision mono and bipolar surgery and micro-surgery, without tissue alterations.
It can also supply HF operative powers for programmable time as short as hundreds of a second.
The unit allows pure CUT, cut-coagulation BLEND, incision with reduced production of eschar ENHANCED, superficial coagulation FORCED COAG, deep coagulation in absence of necrosis SOFT COAG, bipolar CUT, COAG and SEALING, FULGURATION.

The digital reading of delivered power and the operational functions overseeing through microcontroller, assure absolute reliability of work conditions.
Diatermo MB 200 Touch allows a highly professional surgery due to user-friendly and safety solutions normally used.

The neutral electrode and patient/plate safety control are constantly monitored.
The possibility of output functions and output power delivery control, by handle, allows to perform surgery avoiding the surgeon to take his eyes off the operational field.

Software
Developed to provide a simple, functional and intuitive work experience.
Through one finger touch, you can customize screen, work settings, change cut or coagulation power and manage each device function.

Recommended for: CASUALTY / NEUROSURGERY/ PNEUMOLOGY / ENDOSCOPY / FIRST AID / OTORHINOLARYNGOLOGY / UROLOGY / GASTROENTEROLOGY / VASCULAR SURGERY / VETERINARY / GYNECOLOGY

Usable for: ORTHOPAEDICS / TRANS URETHRAL RESECTION TUR / PAEDIATRIC SURGERY / GENERAL SURGERY / PLASTIC SURGERY

Made in Italy.

Technical Specifications

Max power:
PURE CUT: 200 W – 300 Ohm
BLEND: 150 W – 300 Ohm
ENHANCED: 150 W – 300 Ohm
FORCED COAG: 150 W – 200 Ohm
SOFT COAG: 100 W – 200 Ohm
FULGURATION: 100 W – 1000 Ohm
BIPOLAR SEALING: 200 W – 50 Ohm
BIPOLAR COAG: 120 W – 50 Ohm
BIPOLAR CUT: 120 W – 50 Ohm

RF power pulse: emission time 10 ms – 30 sec, interval: 1 – 30
Patient circuit: F
Selectable input voltage: 100 – 240 Vac – 750 VA
Working frequency: 360 KHz
Size (WxHxD) – Weight: 370 x 145 x 300 mm – 6 kg
Controls: Patient/Plate circuit monitoring, Output power monitoring, Self check control
Safety: EN60601-1; EN60601-1-2; EN60601-2-2
Electrical classification: I CF MDD 93/42 / EC: II b

Diatermo MB 200W Touch
